Fronius Symo 10.0-3-M LITE is a three-phase 10 kW grid-tie string inverter engineered for commercial rooftops and light-industrial PV systems. With two independent MPPT trackers, a wide DC input range, integrated WiFi/LAN connectivity and the proven “SuperFlex” design of the Symo family, it enables versatile string layouts and high yield. The “LITE” version streamlines features for cost-efficiency while retaining rugged IP66 outdoor capability and strong efficiency performance. Ideal for integrators seeking a reliable 10 kW class three-phase inverter with streamlined features.
Key Features
-
Nominal AC output of 10 kW (three-phase) for commercial installation.
-
Two MPPT trackers enable flexible module string design and shade-tolerance.
-
Wide DC input voltage range (~200 V–1000 V) and MPP range (~270 V–800 V), supporting high-voltage PV strings.
-
IP66 rated for indoor or outdoor installation; robust cooling and mounting options.
-
Built-in connectivity including WiFi and Ethernet LAN, enabling monitoring via Fronius Solar.web and integration with energy-management systems.
-
LITE version gives reduced cost by omitting some additional modules while maintaining essential performance and warranty.
Technical Data Table
| Parameter | Specification |
|---|---|
| AC nominal output (Pac,r) | 10 kW |
| Number of MPPT trackers | 2 |
| DC input voltage range | ~200 V to 1000 V (depending region) |
| MPP voltage range | ~270 V to 800 V |
| Max. PV generator power (Pdc max) | Approx. 15 kWpeak |
| Max. efficiency | Up to ~97.8% |
| Protection rating | IP66 |
| Dimensions (H × W × D) | ~725 × 510 × 225 mm |
| Weight | ~34.8 kg |
