4800 mm Aluminum Rail for Solar Mounting Structure

KSh3,400.00

  • Anodized AL6005-T5 aluminum extrusion for corrosion and UV resistance.
  • 4800mm length supports 4-6 panels, reducing rail count by 15%.
  • Slotted T-channel design for quick clamp and bracket attachment.
  • High load capacity of 1.4kN/m² for wind/snow up to 2400Pa.
  • Lightweight at 2.5kg per rail for easy handling during installs.
  • Universal fit for 30-50mm clamps, compatible with most PV frames.
Category:

Description

4800 mm Aluminum Rail for Solar Mounting Structure

4800 mm aluminum rail is a high-strength extrusion designed for secure solar panel mounting on roofs or ground systems. Made from anodized AL6005-T5 alloy, it supports multiple panels (up to 4-6 per rail) with universal compatibility for clamps and brackets. Ideal for Kenya’s windy and rainy conditions, it withstands 2400Pa loads and UV exposure, ensuring stable energy production for 25+ years. This lightweight rail (4.8m length) simplifies installation on corrugated or flat roofs, reducing labor by 20% compared to steel alternatives. TUV/CE certified, it features slotted channels for easy adjustment and corrosion resistance in coastal humidity.

4800mm solar rail Key Features

  • Anodized AL6005-T5 aluminum extrusion for corrosion and UV resistance.
  • 4800mm length supports 4-6 panels, reducing rail count by 15%.
  • Slotted T-channel design for quick clamp and bracket attachment.
  • High load capacity of 1.4kN/m² for wind/snow up to 2400Pa.
  • Lightweight at 2.5kg per rail for easy handling during installs.
  • Universal fit for 30-50mm clamps, compatible with most PV frames.

4800mm solar rail Technical Data Table

Specification Value Notes/Source
Material AL6005-T5 Anodized Aluminum UV/corrosion-resistant, 25+ year lifespan
Length 4800mm Supports 4-6 panels per rail
Width 40mm Standard extrusion profile
Height 30mm T-slot channel for accessories
Load Capacity 1.4kN/m² Wind/snow up to 2400Pa
Weight 2.5kg Lightweight for easy transport
Compatibility 30-50mm clamps/rails Universal PV mounting systems
Certifications TUV, CE EN standards for solar structures
Installation Time 15-20 min per rail Adjustable slots for 5-60° pitches
Warranty 10 years Against manufacturing defects
