Victron Phoenix 500 VA 48 V Inverter VE.Direct converts 48 V DC battery power into clean AC output via a pure sine wave, making it ideal for telecommunications, off-grid solar systems, remote sites, small backup installations or industrial signaling loads. With integrated VE.Direct communication for monitoring and configuration, plus an ECO/standby mode to minimize idle consumption, this compact inverter is engineered to reliably power sensitive electronics, emergency loads, and essential devices even in harsh environments.
Key Features
-
Pure sine wave AC output — safe for sensitive electronics (computers, telecom gear, audio, medical)
-
500 VA continuous output rating (suitable for light to moderate loads)
-
Surge / peak capacity — supports equipment startup currents
-
VE.Direct interface — allows system monitoring, tuning, firmware updates, diagnostics
-
ECO / standby mode — reduces idle power draw during light loads
-
Selectable AC output voltage and frequency (e.g. 230 V, 50 Hz or region variant)
-
Adjustable low-voltage alarm, cut-off, restart thresholds, dynamic cut-off behavior
-
Comprehensive protection suite: overload, short circuit, under/over voltage, overtemperature
-
Compact, robust design for installation in tight or remote settings
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 48 V (nominal) |
| Continuous Output (VA) | 500 VA |
| Approximate Continuous Output (W) | ~400 W (for mixed loads) |
| Surge / Peak Capability | Capable of short surge / startup load support |
| Output Voltage (Nominal) | 230 V AC (± tolerance) / or regional variant |
| Output Frequency | 50 Hz (or 60 Hz variant) |
| Efficiency (Peak) | > 90 % (typical for Phoenix VE.Direct series) |
| No-Load / Idle Consumption | Very low (few watts) in normal mode, lower in ECO mode |
| ECO Mode Threshold | Load falls below ~15 W (then enters standby) |
| Protections | Overload, short circuit, under/over voltage, overtemperature |
| Communication / Interface | VE.Direct port |
| Adjustable Settings | Low-voltage alarm, cut-off, restart, dynamic cut-off |
| Dimensions / Weight | See official Phoenix VE.Direct datasheet |
| Battery Connection / Wiring | Screw terminals, recommended cable gauge per installation norms |
| Warranty | Follow Victron standard warranty for Phoenix series |
