Victron Phoenix 500 VA 24 V Inverter converts a 24 V DC battery supply into clean AC power with a pure sine wave output—ideal for off-grid homes, telecommunications, RVs, or backup systems. Compact and efficient, this inverter supports sensitive electronics through stable output, while the VE.Direct interface allows real-time monitoring and configuration. ECO mode reduces power draw at light loads, and integrated protection features ensure reliable, safe operation under diverse conditions.
Key Features
-
Pure sine wave AC output — safe for computers, audio, and sensitive devices
-
500 VA continuous output capacity
-
Surge / peak handling for startup loads
-
VE.Direct interface — digital communication, configuration and system monitoring
-
ECO / standby mode — lowers consumption under light loads (threshold ~15 W)
-
Adjustable low voltage alarm, cut-off, restart & dynamic behavior
-
Selectable output voltage & frequency (50 Hz / 60 Hz, region dependent)
-
Comprehensive protections: overload, short circuit, under/over voltage, overtemperature
-
Very low idle consumption (a few watts)
-
Compact, robust build for space-constrained or mobile installation
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 24 V nominal |
| Continuous Output (VA) | 500 VA |
| Approximate Continuous Output (W) | ~400 W (mixed loads) |
| Surge / Peak Output | ~900 W (short bursts) |
| Output Voltage (Nominal) | 230 V AC ±3 % (or 120 V variant) |
| Output Frequency | 50 Hz (or 60 Hz variant) |
| Efficiency (Peak) | Up to ~90 % |
| No-Load / Idle Consumption | ~6.5 W (or similar, a few watts) |
| ECO Mode Threshold | < ~15 W load to enter standby |
| Protections | Overload, short circuit, under/over voltage, overtemperature |
| Communication / Interface | VE.Direct port |
| Dimensions / Form Factor | See official Victron datasheet (compact design) |
| Warranty | Standard Victron warranty (check vendor) |
