Victron Phoenix 375 VA 24 V Inverter VE.Direct delivers clean, stable AC power from a 24 V DC battery system using a pure sine wave. Ideal for off-grid solar setups, telecom, mobile applications or small backup systems, it supports sensitive electronics and everyday loads. With the VE.Direct communication interface, you can monitor and adjust settings digitally. An ECO / standby mode reduces idle consumption, and built-in protections ensure safe operation in variable conditions.
Key Features
-
Pure sine wave AC output — safe for sensitive loads (computers, audio equipment, communication gear)
-
375 VA continuous rating (approx. 300 W at higher ambient)
-
Strong surge / peak capacity (≈ 700 W) for startup loads
-
VE.Direct interface — allows monitoring, configuration, firmware updates
-
ECO / standby mode — reduces quiescent power draw under light load (< ~15 W)
-
Low idle / no-load consumption (≈ 5–8 W)
-
Wide input voltage range (18.4 – 34 V DC)
-
Selectable frequency & voltage tolerance (230 V ±3 %)
-
Full protection suite: overload, short circuit, over/under voltage, overtemperature
-
Compact, robust design — suitable for constrained spaces or field use
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 18.4 – 34.0 V DC (nominal 24 V) |
| Continuous AC Output | 375 VA (≈ 300 W at higher ambient)] |
| Peak / Surge Output | ~700 W |
| Output Voltage (Nominal) | 230 V AC ±3 % |
| Output Frequency | 50 Hz (or selectable variant) |
| Efficiency (Max) | ~89 % |
| No-Load / Idle Consumption | ~5 – 8 W (lower in ECO mode) |
| ECO / Standby Threshold | ~15 W |
| Protections | Overload, short circuit, under/over voltage, overtemperature |
| Communication / Interface | VE.Direct |
| Dimensions / Mounting | Standard Phoenix series compact form (check Victron datasheet) |
| Recommended Use | Small appliances, lighting, electronics in off-grid or backup systems |
