Victron Phoenix 1.2 kVA 48 V inverter converts 48 V DC battery power into clean 230 V AC, making it ideal for off-grid solar systems, telecommunications, remote sites, or backup power setups. It delivers pure sine wave output, supports VE.Direct digital communication for system monitoring and configuration, and features ECO mode to reduce standby consumption. Built with rigorous protection features and reliable performance, it ensures safe operation for sensitive electronics, motors, and loads in demanding environments.
Key Features
-
Pure sine wave output — safe for computers, audio gear, medical devices
-
1.2 kVA continuous power (for non-linear loads)
-
Robust surge / peak capability to start inductive loads
-
VE.Direct communication port — allows remote monitoring, parameter tuning, diagnostics
-
ECO / standby mode — automatically lowers power draw during light loads
-
Selectable AC output tolerance and frequency (50 Hz / 60 Hz)
-
Built-in protections: over-load, short circuit, over/under voltage, overtemperature
-
Low idle consumption (a few watts)
-
Rugged, compact design suitable for installations in remote or mobile settings
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 48 V |
| Continuous Output Power | ~1,200 VA (non-linear loads) |
| Output Power (for linear loads) | ~1,000 W (approximate) |
| Surge / Peak Capability | Higher surge capacity (e.g. ~2× continuous) |
| Output Voltage (Nominal) | 230 V AC ±3 % |
| Output Frequency | 50 Hz (or selectable to 60 Hz) |
| Efficiency (Peak) | > 90 % (typical) |
| Idle / No-Load Consumption | < ~10 W (lower in ECO mode) |
| AC Output Voltage Window | ~210 – 245 V |
| Protections | Overload, short circuit, over/under voltage, overtemperature |
| Communication Interface | VE.Direct |
| Operative Modes | ECO / Standby |
| Warranty | As per Victron Phoenix series (commonly 5 years) |
