The Victron MultiPlus 5kVA 48V Inverter/Charger is a top-tier, all-in-one energy solution designed for high-demand applications. This 48V inverter/charger integrates a true sine wave inverter, a 120A adaptive battery charger, and an ultra-fast AC transfer switch, ensuring seamless, reliable power for off-grid, solar, RV, marine, and backup systems. The MultiPlus 5kVA 48V features PowerAssist and PowerControl technologies that intelligently balance power use, prevent overloads, and optimize efficiency. It is compatible with lithium, AGM, gel, and flooded batteries, and can be scaled for larger systems with parallel and three-phase operation.
Key Features
-
True Sine Wave Inverter: Provides stable, high-quality AC power, ideal for sensitive electronics
-
120A Adaptive Battery Charger: Advanced four-stage charging ensures long-lasting battery health
-
Ultra-fast AC Transfer (<20 ms): Fast transition between power sources, ensuring no interruptions
-
PowerAssist & PowerControl: Intelligent energy management to optimize power use and prevent overloads
-
Dual-Bank Charging: Simultaneously charges two battery banks for added flexibility
-
Battery Compatibility: Supports lithium, AGM, gel, and flooded batteries
-
Scalable System: Parallel and three-phase operation to expand your setup as needed
-
Remote Monitoring: Control and monitor your system via the Victron VRM portal
-
Compact & Robust Design: Space-saving, durable design for long-term, high-performance operation
Technical Data Table
| Specification | Value / Range |
|---|---|
| Nominal output power | 5000 VA |
| Continuous output power | ~4000 W |
| Input (DC) voltage | 48 V |
| Maximum charge current | 120 A |
| AC input voltage range | 187 – 265 V AC |
| AC input frequency | 45 – 65 Hz |
| Efficiency (inverter) | ~92 – 95 % |
| Transfer switch time | < 20 ms |
| Supported battery types | Lithium, AGM, Gel, Flooded |
| Peak power capability | ~10000 W (short duration) |
| Operating temperature | –20 °C to +50 °C |
| Remote interface | VE.Bus / VRM |
| Scalability | Parallel & 3-phase capable |
