Victron MultiPlus 5kVA 24V Inverter/Charger is a high-performance energy solution designed for demanding off-grid, solar, RV, marine, and backup power systems. This all-in-one unit integrates a true sine wave inverter, a powerful 120A adaptive battery charger, and an ultra-fast AC transfer switch. The MultiPlus 5kVA 24V ensures stable and reliable AC power for sensitive electronics, with the added benefits of PowerAssist and PowerControl technologies to optimize energy use and prevent overloads. It supports various battery types, including lithium, AGM, gel, and flooded, and offers scalability with parallel and three-phase operation for larger installations.
Key Features
-
True Sine Wave Inverter: Delivers clean, grid-quality AC power for sensitive electronics
-
120A Adaptive Battery Charger: Features a four-stage charging process for optimal battery life
-
Ultra-fast AC Transfer (<20 ms): Seamless transition between power sources for continuous power
-
PowerAssist & PowerControl: Intelligent power management to prevent overloads and optimize energy flow
-
Dual-Bank Charging: Supports charging two battery banks simultaneously for flexibility
-
Battery Compatibility: Works with lithium, AGM, gel, and flooded batteries
-
Scalable System: Supports parallel and three-phase operation for larger setups
-
Remote Monitoring: Easy system diagnostics and control via VE.Bus and VRM portal
-
Compact & Efficient Design: High energy efficiency with a robust and durable design
Technical Data Table
| Specification | Value / Range |
|---|---|
| Nominal output power | 5000 VA |
| Continuous output power | ~4000 W |
| Input (DC) voltage | 24 V |
| Maximum charge current | 120 A |
| AC input voltage range | 187 – 265 V AC |
| AC input frequency | 45 – 65 Hz |
| Efficiency (inverter) | ~92 – 95 % |
| Transfer switch time | < 20 ms |
| Supported battery types | Lithium, AGM, Gel, Flooded |
| Peak power capability | ~10000 W (short duration) |
| Operating temperature | –20 °C to +50 °C |
| Remote interface | VE.Bus / VRM |
| Scalability | Parallel & 3-phase capable |
