Victron MultiPlus 500VA 48V Inverter is a compact, all-in-one power solution that combines a true sine wave inverter, an advanced battery charger, and a high-speed AC transfer switch. Designed for reliable off-grid, solar, marine, and RV applications, it delivers clean, stable power while protecting sensitive electronics. With PowerControl and PowerAssist technologies, the MultiPlus balances loads, prevents overloads, and optimizes available power. Supporting multiple battery chemistries, including lithium, AGM, gel, and flooded types, it offers long-term efficiency and remote monitoring options.
Key Features
-
Pure sine wave inverter for grid-quality AC output
-
Four-stage adaptive charger for optimal battery life
-
Dual-bank battery charging capability
-
Ultra-fast AC transfer (<20 ms) for seamless operation
-
PowerControl & PowerAssist prevent overload and stabilize supply
-
Works with lithium, AGM, gel, and flooded batteries
-
Stackable for parallel or three-phase configurations
-
Remote monitoring via Victron VRM and VE.Bus interface
-
Durable, efficient, and space-saving design
Technical Data Table
| Specification | Value / Range |
|---|---|
| Nominal output power | 500 VA |
| Continuous output power | ~ 430 W (depending on load) |
| Input (DC) voltage | 48 V |
| Maximum charge current | 10 A (approx.) |
| AC input voltage range | 187 – 265 V AC |
| AC input frequency | 45 – 65 Hz |
| Efficiency (inverter) | ~ 90–95 % |
| Transfer switch time | < 20 ms |
| Supported battery types | Lithium, AGM, Gel, Flooded |
| Operating temperature | –20 °C to +50 °C |
| Remote interface | VE.Bus / VRM |
| Scalability | Parallel & 3-phase capable |
