The Victron MultiPlus 2kVA 24V Inverter/Charger is an advanced, all-in-one power solution that combines a pure sine wave inverter, high-performance battery charger, and ultra-fast AC transfer switch in one compact unit. Designed for 24V systems, it provides reliable, stable AC power for off-grid, RV, marine, and backup power systems. With its PowerAssist and PowerControl technologies, the MultiPlus 2kVA ensures efficient power management by preventing overloads and optimizing energy use. It supports multiple battery chemistries, including lithium, AGM, gel, and flooded, and offers scalability with parallel and three-phase capabilities.
Key Features
-
True sine wave inverter for clean, grid-quality AC power
-
100A adaptive four-stage battery charger for optimal battery performance
-
Ultra-fast AC transfer (<20 ms) for seamless switching between power sources
-
PowerAssist & PowerControl to dynamically manage power and prevent overloads
-
Dual-bank charging support for auxiliary batteries
-
Compatible with lithium, AGM, gel, and flooded batteries
-
Parallel & three-phase operation with multiple units
-
Remote monitoring via VE.Bus and VRM portal
-
Compact, efficient, and durable design
Technical Data Table
| Specification | Value / Range |
|---|---|
| Nominal output power | 2000 VA |
| Continuous output power | ~1600 W |
| Input (DC) voltage | 24 V |
| Maximum charge current | 100 A |
| AC input voltage range | 187 – 265 V AC |
| AC input frequency | 45 – 65 Hz |
| Efficiency (inverter) | ~92 – 95 % |
| Transfer switch time | < 20 ms |
| Supported battery types | Lithium, AGM, Gel, Flooded |
| Peak power capability | ~4000 W (short duration) |
| Operating temperature | –20 °C to +50 °C |
| Remote interface | VE.Bus / VRM |
| Scalability | Parallel & 3-phase capable |
