Victron EasySolar-II 5kVA inverter is an all-in-one hybrid inverter/charger + MPPT solar controller + system controller in a single enclosure. It integrates a MultiPlus-II inverter/charger, SmartSolar MPPT 250/100 charger, and GX controller, all prewired for fast installation. With Wi-Fi / Bluetooth, remote monitoring via VictronConnect/VRM, and advanced PowerAssist / PowerControl, it ensures seamless battery charging, solar conversion and grid/generator support under load. Ideal for residential, off-grid and backup power systems.
Key Features
-
All-in-one hybrid unit combining inverter, charger & MPPT controller
-
5 kVA continuous output, 4 000 W rated at 25 °C
-
MPPT 250/100 (maximum 100 A solar charge) and 5 800 W PV power input
-
High peak / surge capacity (≈ 9 000 W)
-
PowerAssist & PowerControl to support weak grids or generators by supplementing from batteries
-
GX controller with Wi-Fi, Ethernet, VE.Direct, USB — remote monitoring and configuration via VictronConnect / VRM portal
-
Very efficient (up to ~96 %)
-
Multiple protections: over/under voltage, overload, short circuit, temperature, AC input fault
-
Automatic transfer switch (50 A) for AC input/backup source
-
Supports parallel and 3-phase setups with multiple units via GX control
Technical Data Table
| Parameter | Specification |
|---|---|
| Nominal DC Input Voltage | 38 – 66 V DC |
| Rated Output, 25 °C | 5 000 VA / 4 000 W |
| Output Power @ 40 °C | 3 700 W |
| Output Power @ 65 °C | 3 000 W |
| Surge / Peak Output | ~9 000 W |
| Output Voltage | 230 V AC ± 2 % |
| Output Frequency | 50 Hz ± 0.1 % |
| Max Efficiency | ~96 % |
| No-load / Idle Power | 18 W |
| Solar MPPT Controller | 250/100-Tr (100 A) |
| Max PV Power | 5 800 W (open circuit 250 V) |
| AC Input Range | 187 – 265 V AC, 45 – 65 Hz |
| Charger Current | 70 A (48 V) |
| Transfer Switch | 50 A built-in |
| Weight | ~ 31 kg |
| Dimensions (HxWxD) | ~ 565 × 323 × 148 mm |
| Operating Temperature | −40 °C to +65 °C (fan assisted) |
