HUAWEI 200 kW Grid Tie Inverter | SUN2000-200KTL-M1 Three Phase

Description

Huawei 200kW Grid Tie Inverter | SUN2000-200KTL-M1 Three Phase – Utility-Scale Solar Power Solution

Buy Huawei 200kW Grid Tie Inverter for your next utility-scale or large commercial solar project in Kenya. The Huawei SUN2000-200KTL-H2 inverter is a high-efficiency three-phase system, purpose-built for grid-tie installations demanding serious power. With a max AC active power of 215kW and advanced features like 24 MPPTs and smart IV curve diagnostics, this inverter ensures exceptional energy harvesting even in challenging environments.

As a trusted source for Huawei solar inverters in Kenya, SolarShop Africa brings you verified products and technical support. Whether you’re checking the latest Huawei Grid Tie Inverters Prices in Kenya or looking to upgrade your installation with the Huawei inverter SUN2000 series, we provide complete solutions. Pair this inverter with solar arrays and explore our packages to get the complete solar system price in Kenya at unbeatable rates.

Designed to optimize large energy systems, the Huawei SUN2000-200KTL H2 offers AFCI protection, robust surge capabilities, and efficient thermal control. Don’t settle for less – power your site with trusted technology that scales. For professionals comparing commercial models like the Huawei sun2000 60ktl m1 inverter or expanding to 200kW needs, we deliver top-tier tools for top-tier output. Order your Huawei inverter today and electrify your energy goals.

HUAWEI 200kW grid tie inverter Three Phase Key Features & Benefits:

✔ 200kW Three-Phase Output – For large-scale PV systems
✔ 99% Maximum Efficiency – Industry-leading performance
✔ 24 MPPT Inputs – Ultimate flexibility for complex array layouts
✔ Smart IV Curve Diagnosis 4.0 – 95% fault detection accuracy
✔ AFCI Protection – Enhanced safety against arc faults
✔ IP66 Protection – Dustproof and waterproof for harsh environments
✔ 200% DC Overloading – Future-proof system design
✔ Huawei FusionSolar AI – Predictive maintenance and yield optimization

Technical Highlights:

• 1500V DC Input – Higher string voltage for reduced BoS costs
• Nighttime Reactive Power Support – Grid service capabilities
• PID Recovery & Prevention – Maintains module performance
• -40°C to +60°C Operation – Arctic to desert ready
• Natural Cooling – No moving parts for silent operation

Ideal Applications:

• Utility-scale solar farms
• Industrial rooftops
• PV power plants
• Large commercial installations
• Solar tracking systems

HUAWEI 200kW grid tie inverter Three Phase Technical Specifications Table

Specification	Details
Model	SUN2000-200KTL-M1
Type	Three-Phase Grid-Tie
Max. Output Power	200kW
Peak Efficiency	99%
MPPT Channels	24
Max. DC Input	1500V
AC Output Voltage	480V/600V (configurable)
Frequency	50/60Hz
Protection Rating	IP66
Operating Temperature	-40°C to +60°C
Cooling System	Natural convection
Communication	RS485, Ethernet, 4G (optional)
Dimensions	1100 × 800 × 350 mm
Weight	120 kg
Warranty	10 years

Buy HUAWEI 200kW grid tie inverter Three Phase online In Kenya at the best price at SolarShop Africa
