Experience elite-level energy control with the SUNSYNK 12kW Hybrid Inverter. Engineered for large residences, small businesses, and properties with the highest energy demands, this inverter delivers unmatched power and intelligence. It represents the pinnacle of the SUNSYNK series, capable of handling significant electrical loads while providing complete energy independence.
With a massive 15kW PV input and a robust 12kW output power, this unit ensures your solar array operates at absolute maximum efficiency, drastically reducing your reliance on the grid. Its advanced design supports extensive battery storage and allows for parallel expansion up to a colossal 72kW. For homeowners who refuse to compromise on power, performance, or resilience, the SUNSYNK 12kW inverter is the definitive choice for a future-proof energy system.
Key Features
-
Elite 12kW Output Power: Designed to effortlessly power large homes with high-demand appliances, including multiple air conditioning units, electric water heating, and pool pumps, even during a grid outage.
-
Massive 15kW PV Input: Harvests more solar energy than ever before, with a huge PV array capacity that ensures rapid battery charging and maximizes self-consumption, even in sub-optimal weather.
-
Advanced Dual MPPT Controllers: Two high-current MPPT trackers allow for complex, multi-directional solar panel installations, optimizing energy harvest from both morning and afternoon sun.
-
Uninterruptible Backup Power: The dedicated backup port guarantees that your essential and high-power circuits remain online 24/7, providing total peace of mind during blackouts.
-
High-Current Battery Charging: Supports a massive 200A charge/discharge current, compatible with 48V battery banks (including LiFePO4), enabling the use of high-performance battery systems for extended backup.
-
Ultimate Scalability: Connect up to 6 units in parallel to create a monumental 72kW system, ideal for large estates or commercial applications requiring immense power.
-
Comprehensive Grid & Generator Support: Offers flexible charging options, including grid charging during low-tariff periods and integration with a standby generator for ultimate energy security.
-
Professional Monitoring & Control: Monitor every aspect of your system’s performance in real-time and adjust settings remotely via the intuitive SUNSYNK app for full system management.
Technical Data Table
| Category | Specification |
|---|---|
| Model | SUNSYNK 12kW 48V Hybrid Inverter |
| Rated Output Power | 12000W |
| Max. PV Input Power | 15000W |
| Max. PV Input Voltage (Vdc) | 500V |
| Start Voltage (Vdc) | 120V |
| MPPT Voltage Range | 125V ~ 425V |
| Number of MPP Trackers | 2 |
| Max. PV Input Current (per MPPT) | 25A + 25A |
| Rated Grid Voltage | 230VAC |
| Output Frequency | 50Hz/60Hz (Selectable) |
| Grid Charging Current | 120A |
| Battery Voltage | 48V |
| Max. Battery Charging/Discharging Current | 200A |
| Communication | RS485, Wi-Fi/GPRS (Optional) |
| Parallel Capability | Up to 6 units |
| Weight | Approx. 22 kg |
| Dimensions (H x W x D) | Approx. 510 x 460 x 200 mm |
| Operating Temperature | -25°C to +60°C |
| Cooling Method | Smart Fan Cooling |
