Victron Quattro 15 kVA 48 V Inverter Charger delivers high power for large homes, clinics, small businesses and hybrid solar installations. You get 15,000 VA continuous power, dual AC inputs (grid + generator), auto changeover, and a powerful 200 A charger for fast battery recovery. It supports lead-acid and lithium battery banks. It scales via parallel or three-phase configuration.
Key Features
• True sine wave output protects sensitive electronics
• Dual AC inputs with automatic switching between sources
• PowerAssist and PowerControl functions to avoid overloads on limited AC sources
• Integrated transfer switch, <20 ms switchover time for no interruption
• High charge current (200 A) for fast battery charging
• Scalable system: parallel or three-phase setup for larger power demands
victron quattro 15kva 48v inverter charger Technical Data Table
| Specification | Detail |
|---|---|
| Nominal Battery Voltage (DC) | 48 V |
| DC Input Voltage Range | 38-66 V |
| Continuous Output Power @ 25 °C | 15,000 VA (~12,000 W) |
| Output Voltage / Frequency | 230 VAC ±2 %, 50 Hz (adjustable) |
| AC Input Voltage Range | 187-265 VAC, 45-65 Hz |
| Peak / Surge Power | ~25,000 W |
| Max Efficiency | ~96 % |
| Charge Current (AC charger) | 200 A |
| Zero-Load Power Consumption | ~110 W |
| Dimensions (HxWxD) | 572 × 488 × 344 mm |
| Weight | ~ 72 kg |
| Operating Temperature | -40 to +65 °C |
