Victron Phoenix Smart 3kVA 24V inverter delivers dependable, clean AC power from a 24 V battery source thanks to its pure sine wave output and advanced electronics. Equipped with built-in Bluetooth / VE.Direct connectivity, it allows real-time monitoring and configuration via the VictronConnect app. With high surge capability, ECO mode for energy savings, and full protection features, this inverter is ideal for off-grid solar systems, mobile installations, backup power, and sensitive electronics.
Key Features
-
Pure sine wave AC output — safe for sensitive electronics
-
3,000 VA continuous output at 25 °C
-
High surge / peak capacity to support inductive loads
-
Bluetooth + VE.Direct interface — for configuration, monitoring, firmware updates
-
ECO / standby mode — reduces idle power draw under light loads
-
Wide DC input range: 18.6 V to 34 V DC
-
Tight AC output: 230 V ±2%
-
Comprehensive protection: over/under voltage, overload, short circuit, overtemperature
-
Modular design allows paralleling or 3-phase operation with multiple units
Technical Data Table
| Parameter | Specification |
|---|---|
| Input Voltage Range | 18.6 V – 34.0 V DC |
| Continuous Output Power | 3,000 VA (at 25 °C) |
| Peak / Surge Capacity | High (for startup demands) |
| Output Voltage | 230 V AC ±2% |
| Output Frequency | 50 Hz (±0.1 Hz) |
| Efficiency (Max) | High (typical for Smart series) |
| Idle / No-Load Consumption | Low — optimized in ECO mode |
| Protections | Overload, short circuit, over/under voltage, overtemperature |
| Communication / Interface | Bluetooth + VE.Direct (via VictronConnect) |
| Dimensions / Mounting | As per Victron 3 kVA Smart 24 V drawing |
| Paralleling / 3-Phase | Supports multiple units in parallel or 3-phase configuration |
