Victron Phoenix Smart 2kVA 24V inverter transforms 24 V DC battery power into a stable, pure sine wave AC output. Designed for off-grid, mobile, and backup systems, it features built-in Bluetooth / VE.Direct connectivity for system monitoring and configuration via VictronConnect. With high surge capability, ECO mode, and full protection mechanisms, this inverter delivers reliable power to sensitive electronics, appliances, and loads in varied environments.
Key Features
-
Pure sine wave AC output — safe for computers, home appliances, and sensitive devices
-
2,000 VA continuous output at 25 °C (derated at high ambient)
-
High surge / peak capacity (approx. 4,000 W)
-
Bluetooth + VE.Direct interface — full monitoring and configuration via VictronConnect
-
ECO / standby mode to minimize idle power consumption
-
Wide DC input range (~18.6 V to ~34 V)
-
Output: 230 V AC ±2 %, selectable 50 Hz or 60 Hz
-
Comprehensive protections: overload, short circuit, over/under voltage, overtemperature
-
Compact, slim metal casing — easier installation with accessible terminals
Technical Data Table
| Parameter | Specification |
|---|---|
| Model | Phoenix Smart 24 / 2000 |
| DC Input Voltage Range | ~18.6 V to ~34 V |
| Continuous AC Output | 2,000 VA at 25 °C |
| Derated Output (e.g. 40 °C / 65 °C) | ~1,450 / ~1,000 W |
| Surge / Peak Output | ~4,000 W |
| Output Voltage | 230 V AC ±2 % |
| Output Frequency | 50 Hz or 60 Hz (selectable) |
| Efficiency (Max) | ~92 % |
| No-Load / Idle Consumption | ~9 W (≈1.3 W in ECO mode) |
| ECO Mode Idle | ~1.3 W |
| Protections | Overload, short circuit, over/under voltage, overtemperature |
| Communication / Interface | Bluetooth + VE.Direct |
| Dimensions & Casing | Slim metal design; improved terminal access |
