Victron Phoenix Smart 1.6 kVA Inverter combines power, flexibility and connectivity in a compact form. It converts 12 V battery energy into clean, stable pure sine wave AC output (230 V or 120 V version) while offering a built-in Bluetooth / VE.Direct interface for real-time monitoring and configuration via smartphone or tablet. With strong surge capability, ECO mode, and comprehensive protection, this inverter is ideal for off-grid homes, mobile power systems, backup installations, and sensitive electronics.
Key Features
-
Pure sine wave AC output — safe for sensitive electronics (computers, audio, medical equipment)
-
1,600 VA continuous output at 25 °C (derated at higher ambient)
-
High peak / surge capacity (up to ~3,000 W)
-
Built-in Bluetooth / VE.Direct communication — full configuration via VictronConnect app
-
ECO / standby mode — reduces idle power draw when load is low
-
Wide DC input voltage window (9.3 V to 17.0 V)
-
Output voltage range: 210-245 V AC, support for both 50 Hz and 60 Hz
-
Built-in protections: overcurrent, over/under voltage, overtemperature, short circuit
-
Low idle loss (~8 W)
-
Compact, robust design suitable for mounting in constrained or mobile installations
Technical Data Table
| Parameter | Specification |
|---|---|
| Model | Phoenix Smart 12 / 1600 (1.6 kVA) |
| DC Input Voltage Range | 9.3 V to 17.0 V |
| Continuous AC Output | 1,600 VA @ 25 °C (derated at higher ambient) |
| Surge / Peak Capability | Up to ~3,000 W |
| Output Voltage | 230 V AC ± tolerance (210-245 V range) |
| Output Frequency | 50 Hz (or 60 Hz variant) |
| Efficiency (Max) | ~92 % |
| Idle / No-Load Consumption | ~8 W |
| ECO Mode Threshold / Behavior | Switch to standby under light load; configurable via app |
| Protections | Overload, short circuit, over/under voltage, overtemperature |
| Communication | Bluetooth / VE.Direct (VictronConnect compatible) |
| Dimensions / Mounting | Slim profile for flexible placement |
