Victron Energy

VICTRON PHOENIX 800VA 12V INVERTER VE DIRECT

KSh33,500.00

  • Pure sine wave AC output — safe for sensitive electronics (computers, medical devices, audio)

  • 800 VA continuous output (mixed loads)

  • Strong surge / peak capability to start inductive loads

  • VE.Direct interface — enables remote monitoring, firmware upgrades, configuration

  • ECO / standby mode — reduces power draw during light loads

SKU: 10-VIC-0109 Categories: ,

Description

Victron Phoenix 800 VA 12 V Inverter converts 12 V DC battery energy into stable AC power (230 V or 120 V, depending on region), delivering a clean pure sine wave output. Compact and efficient, it’s ideal for off-grid solar, RVs, telecom systems or backup installations. With its VE.Direct communication port, you can monitor and configure the inverter settings, while ECO / standby mode minimizes idle consumption. Built-in protections make it reliable for running sensitive electronics and moderate loads in challenging environments.

Key Features

  • Pure sine wave AC output — safe for sensitive electronics (computers, medical devices, audio)

  • 800 VA continuous output (mixed loads)

  • Strong surge / peak capability to start inductive loads

  • VE.Direct interface — enables remote monitoring, firmware upgrades, configuration

  • ECO / standby mode — reduces power draw during light loads

  • Customizable low-voltage alarm, cut-off and restart thresholds, dynamic cut-off behavior

  • Selectable AC output voltage tolerance & frequency (region dependent)

  • Full protection suite: overload, short circuit, under/over voltage, over temperature

  • Ultra-low idle consumption (< 10 W, < 1 W in ECO mode)

  • Durable and compact for flexible mounting

Technical Data Table

Parameter Specification
DC Input Voltage 12 V nominal
Input Voltage Range ~9.5 V – ~17 V (depending on model tolerances)
Continuous Output (VA) 800 VA
Approximate Continuous Output (W, mixed loads) ~640 W
Surge / Peak Capability ~1,600 W (2× continuous)
Output Voltage (Nominal) 230 V AC ±3 % (region variant)
Output Frequency 50 Hz (or 60 Hz in alternate versions)
Efficiency (Peak) > 90 % (typical)
No-Load / Idle Consumption < 10 W (and < 1 W in ECO mode)
Protections Overload, short circuit, under/over voltage, over temperature
Communication Interface VE.Direct
Modes & Controls ECO / Standby, adjustable cut-off, dynamic cut-off behavior
Warranty 5 years (Victron standard)
