Victron Phoenix 800 VA 12 V Inverter converts 12 V DC battery energy into stable AC power (230 V or 120 V, depending on region), delivering a clean pure sine wave output. Compact and efficient, it’s ideal for off-grid solar, RVs, telecom systems or backup installations. With its VE.Direct communication port, you can monitor and configure the inverter settings, while ECO / standby mode minimizes idle consumption. Built-in protections make it reliable for running sensitive electronics and moderate loads in challenging environments.
Key Features
-
Pure sine wave AC output — safe for sensitive electronics (computers, medical devices, audio)
-
800 VA continuous output (mixed loads)
-
Strong surge / peak capability to start inductive loads
-
VE.Direct interface — enables remote monitoring, firmware upgrades, configuration
-
ECO / standby mode — reduces power draw during light loads
-
Customizable low-voltage alarm, cut-off and restart thresholds, dynamic cut-off behavior
-
Selectable AC output voltage tolerance & frequency (region dependent)
-
Full protection suite: overload, short circuit, under/over voltage, over temperature
-
Ultra-low idle consumption (< 10 W, < 1 W in ECO mode)
-
Durable and compact for flexible mounting
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 12 V nominal |
| Input Voltage Range | ~9.5 V – ~17 V (depending on model tolerances) |
| Continuous Output (VA) | 800 VA |
| Approximate Continuous Output (W, mixed loads) | ~640 W |
| Surge / Peak Capability | ~1,600 W (2× continuous) |
| Output Voltage (Nominal) | 230 V AC ±3 % (region variant) |
| Output Frequency | 50 Hz (or 60 Hz in alternate versions) |
| Efficiency (Peak) | > 90 % (typical) |
| No-Load / Idle Consumption | < 10 W (and < 1 W in ECO mode) |
| Protections | Overload, short circuit, under/over voltage, over temperature |
| Communication Interface | VE.Direct |
| Modes & Controls | ECO / Standby, adjustable cut-off, dynamic cut-off behavior |
| Warranty | 5 years (Victron standard) |
