Victron Phoenix 375VA 48V Inverter VE.Direct converts 48V DC battery power into a pure sine wave 230V AC output — ideal for off-grid, mobile, and backup power systems. Built for reliability and efficiency, it safely powers sensitive electronics, lighting, and communication equipment. The VE.Direct communication port allows for easy monitoring and configuration via VictronConnect. With high peak power capability, ECO mode for low consumption, and full protection features, this inverter delivers professional-grade performance in a compact design — perfect for solar setups, vehicles, or remote installations.
Key Features
-
Pure sine wave output — ensures safe operation for all sensitive devices
-
375VA continuous power (≈300W at high temperatures)
-
700W peak power to handle startup surges
-
VE.Direct interface — real-time monitoring and configuration
-
ECO mode reduces power draw during low loads
-
Wide DC input range: 38V – 66V
-
High efficiency up to 89%
-
Comprehensive protections: overload, short circuit, over-temperature, low/high battery
-
Compact and lightweight for flexible installation
-
Proven Victron reliability backed by worldwide service
Technical Data Table
| Parameter | Specification |
|---|---|
| Model | Victron Phoenix 375VA 48V Inverter VE.Direct |
| Continuous Output Power | 375VA / ~300W at 25°C |
| Peak Power | ~700W |
| Input Voltage Range | 38V – 66V DC |
| Output Voltage | 230V AC ±3% |
| Output Frequency | 50Hz (±0.1%) |
| Efficiency (Max) | ~89% |
| No-Load Power Consumption | ~5.6W (lower in ECO mode) |
| ECO Mode Activation | Below ~15W load |
| Waveform | Pure Sine Wave |
| Protection Features | Overload, Short Circuit, Over-Temperature, Low/High Battery |
| Communication Port | VE.Direct |
| Operating Temperature | -40°C to +65°C |
| Weight / Dimensions | 1.9 kg / 86 × 165 × 260 mm (W × H × D) |
