Victron Phoenix 375 VA inverter delivers clean AC power from a 12 V battery source via a pure sine wave output. Though often marketed for 120 V / 60 Hz regions, its high quality electronics, VE.Direct communication interface, and smart ECO mode make it ideal for remote, mobile or backup setups. Compact and efficient, it’s suited for powering small loads, sensitive electronics, lighting, or communication equipment with dependability and safety.
Key Features
-
Pure sine wave AC output — suitable for sensitive electronics (computers, audio)
-
375 VA continuous rating (≈ 300 W in warm conditions)
-
Peak / surge power up to ~700 W
-
VE.Direct interface — for digital monitoring, setup and diagnostics
-
Smart ECO / standby mode — reduces consumption when loads are light (min load ~15 W)
-
Low no-load draw (~5.6 W)
-
Protection suite: overload, overtemperature, short circuit, over/under voltage
-
Compact and rugged — suitable for marine, off-grid or mobile installations
-
Automatic switching back from ECO when load rises
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 12 V nominal |
| Continuous Output (VA) | 375 VA |
| Continuous Output (W, mixed loads) | ~300 W (at higher ambient) |
| Surge / Peak Output | ~700 W |
| Output Voltage (Nominal) | 120 V AC in many versions (for 60 Hz markets) |
| Output Frequency | 60 Hz (region dependent) |
| Efficiency (Max) | ~89 % |
| No-Load / Idle Consumption | ~5.6 W |
| ECO Mode Threshold | ~15 W |
| Protections | Overload, short circuit, over/under voltage, over temperature |
| Communication Interface | VE.Direct |
| Typical Use | Lighting, small loads, electronics, communication gear |
| Warranty & Build | Rugged design, check vendor warranty |
