Victron Phoenix 375 VA 24 V Inverter VE.Direct transforms 24 V DC battery power into a clean, stable AC output (230 V ±3 %) using pure sine wave technology. Compact but powerful, it’s ideal for off-grid solar, telecom, backup power, or small systems running sensitive electronics. Using its VE.Direct interface, you can monitor performance, adjust settings, and integrate remote control. With ECO mode and low idle draw, it maintains efficiency while safeguarding battery life, and built-in protections ensure reliable operation under varied conditions.
Key Features
-
Pure sine wave AC output — safe for computers, communication gear, audio, and sensitive electronics
-
375 VA continuous output (approx. 300 W at elevated temperature)
-
Peak / surge capacity ~700 W to handle startup loads
-
VE.Direct interface — digital monitoring, configuration, firmware updates
-
ECO (standby) mode — switches off under light load (< 15 W)
-
Ultra-low zero load consumption: ~5.6 W typical, less in ECO mode
-
Wide input voltage range: 18.4 – 34.0 V DC
-
Full protection suite: overload, short circuit, under/over voltage, overtemperature
-
Compact, rugged design for installation flexibility
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage Range | 18.4 – 34.0 V DC |
| Continuous AC Output | 375 VA (≈ 300 W at high ambient) |
| Peak / Surge Output | ~700 W |
| Output Voltage (Nominal) | 230 V AC ±3 % |
| Output Frequency | 50 Hz (region dependent) |
| Efficiency (Max) | ~89 % |
| No-Load / Idle Consumption | ~5.6 W typical; lower in ECO mode |
| ECO Mode Activation Threshold | ~15 W load |
| Protections | Overload, short circuit, under/over voltage, overtemperature |
| Communication / Interface | VE.Direct |
| Dimensions / Mounting | Compact form factor — refer to Victron datasheet for mechanical specifics |
