Victron Phoenix 250VA 48V Inverter VE.Direct converts 48 V DC battery power into a pure sine wave AC output (230 V or 120 V variant) suitable for sensitive electronics, communication equipment, lighting, and small appliances. Compact and reliable, this inverter offers digital monitoring and configuration via the VE.Direct interface. ECO mode ensures low idle consumption, while its surge capability and protection systems safeguard connected loads and battery systems. Ideal for remote, off-grid, telecom or backup installations requiring a compact, high-efficiency inverter.
Key Features
-
Pure sine wave AC output — safe for computers, audio, telecom gear
-
250VA continuous output at 25 °C
-
Surge / peak support up to ~400W
-
VE.Direct interface — for monitoring, parameter setup, firmware updates
-
ECO / standby mode — switches off under light load (< ~15W)
-
Low zero-load consumption (a few watts)
-
Adjustable AC output voltage / frequency (230 V / 120 V, 50 Hz / 60 Hz)
-
Full protection: overload, short circuit, over/under voltage, overtemperature
-
Compact form factor; dimensions ~ 86 × 165 × 260 mm, weight ~ 2.4 kg
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 48 V nominal |
| Continuous Output (VA) | 250 VA at 25 °C |
| Approximate Output (W) | ~ (for mixed loads) — lower when ambient high |
| Surge / Peak Output | ~400 W |
| Output Voltage | 230 V AC ±3% (or 120 V variant) |
| Output Frequency | 50 Hz or 60 Hz selectable |
| Efficiency (Max) | ~88 % |
| No-Load / Idle Consumption | A few watts (exact small values) |
| ECO Mode Threshold | ~15 W load |
| Protections | Overload, short circuit, over/under voltage, overtemperature |
| Communication / Interface | VE.Direct |
| Dimensions | ~86 × 165 × 260 mm |
| Weight | ~2.4 kg |
