Victron Phoenix 250VA 24V Inverter VE.Direct converts 24 V DC battery power into a clean, pure sine wave 230 V (or 120 V in some variants) AC output, suitable for sensitive electronics, small appliances, and communication gear. Compact and efficient, this inverter fits off-grid solar systems, backup power installations, or mobile setups. You can monitor and configure settings via its VE.Direct interface. With ECO mode to reduce idle consumption and strong surge support, it delivers dependable performance while protecting both the load and the battery system.
Key Features
-
Pure sine wave AC output — safe for sensitive electronics
-
250VA continuous rating (≈ 200W to 175W under varying temperature/conditions)
-
Surge / peak capacity up to ~400W to support startup loads
-
VE.Direct communication port — allows real-time monitoring, configuration, firmware updates
-
ECO / standby mode — reduces idle consumption when load is low (below ~15W)
-
Adjustable low voltage alarm, cut-off, restart thresholds and dynamic cut-off behavior
-
Wide operating voltage tolerance to accommodate battery voltage fluctuations
-
Comprehensive protection: overload, short-circuit, over/under voltage, overtemperature
-
Compact and robust form factor — dimensions ~ 86 × 165 × 260 mm, weight ~2.4 kg
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 24 V nominal |
| Continuous Output (VA) | 250 VA |
| Approximate Output (W) | ~200 W (at 25 °C), ~175 W at higher temperature/load stress |
| Surge / Peak Output | ~400 W |
| Output Voltage (Nominal) | 230 V AC ±3 % (or 120 V variant in some markets) |
| Output Frequency | 50 Hz (region dependent) |
| Efficiency (Max) | ~88 % |
| No-Load / Idle Consumption | Low (a few watts) |
| ECO Mode Threshold | ~15W load threshold |
| Protection Features | Overload, short circuit, under/over voltage, overtemperature |
| Communication / Interface | VE.Direct |
| Dimensions | ~ 86 × 165 × 260 mm |
| Weight | ~ 2.4 kg |
