Victron Phoenix 250VA 12V Inverter transforms 12 V DC battery input into clean, stable AC output (230 V or 120 V depending on region), delivering a pure sine wave ideal for sensitive electronics, appliances and communication equipment. Compact and efficient, it is perfect for small off-grid systems, mobile setups, backup power or RV use. Via its VE.Direct interface, the inverter supports real-time monitoring, firmware updates and configuration. With ECO mode and low idle consumption, it conserves battery power while offering reliable surge support and full protection features.
Key Features
-
Pure sine wave AC output — safe for computers, audio gear, communication devices
-
250 VA continuous rating (≈ 200–220 W for mixed loads)
-
Peak / surge capability up to ~400 W to support startup loads
-
VE.Direct port — enables digital monitoring, settings adjustment, diagnostics
-
ECO / standby mode — switches to low consumption when load < ~15 W
-
Low no-load consumption (~ a few watts)
-
Wide input voltage tolerance for stable operation under battery fluctuations
-
Comprehensive protection: overload, short-circuit, over/under voltage, overtemperature
-
Compact and robust design for mobile, RV, telecom or backup installations
Technical Data Table
| Parameter | Specification |
|---|---|
| DC Input Voltage | 12 V nominal |
| Continuous Output (VA) | 250 VA |
| Approximate Continuous Output (W) | ~200–220 W (for mixed loads) |
| Surge / Peak Output | ~400 W |
| Output Voltage | 230 V AC ±3 % (or 120 V variant) |
| Output Frequency | 50 Hz (or 60 Hz in region variant) |
| Efficiency (Max) | ~87 % |
| No-Load / Idle Consumption | A few watts (very low) |
| ECO Mode Threshold | ~15 W load |
| Protection Features | Overload, short circuit, over/under voltage, overtemperature |
| Communication Interface | VE.Direct |
| Warranty | 5 years (typical for Phoenix VE.Direct series) |
