GoodWe 25 kW Ongrid Grid-Tied Solar Inverter (GW25K -MT) is a high-performance, three-phase solar inverter ideal for residential and small commercial installations. Engineered for efficiency and reliability, this inverter supports advanced grid compliance, rapid MPPT tracking, and real-time monitoring. Its compact design, quiet operation, and 150% DC oversizing capability ensure maximum energy harvest and optimal ROI for your solar investment.
⭐GoodWe 25kW Grid-tied inverter Key Features
-
Rated Power: 15,000W for high-output solar systems.
-
DC Oversizing: 150% DC input oversizing to maximize performance.
-
AC Overloading: 110% AC output overloading for better utilization.
-
Smart Monitoring: Wi-Fi, RS485, and optional LAN for remote monitoring.
-
Advanced Protection: IP66-rated for outdoor durability.
-
Safe & Reliable: Supports AFCI (Arc Fault Circuit Interrupter) and integrated surge protection.
📊GoodWe 25kW Grid-tied inverter Technical Data
| Specification | Details |
|---|---|
| Model | GW25K -MT |
| Type | Three-Phase Grid-Tied Inverter |
| Rated Output Power | 25,000 W |
| Max DC Voltage | 1,100 V |
| Start-up Voltage | 200 V |
| MPPT Inputs | 2 |
| Efficiency | 98.3% Max |
| Communication | RS485, Wi-Fi, Optional LAN |
| Protection Rating | IP66 |
| Dimensions | ~480 x 590 x 200 mm |
| Weight | ~25 kg |
Compact Size & High Power Density
For GoodWe 25kW Grid-tied inverter, it is relatively small and light, which makes it easily transportable. Its compact design also allows for quick and easy installation.
