If you’re gearing up for a solid commercial or large residential solar setup, the ATESS HPS30 hybrid inverter is a robust 30kW/33kVA three-phase hybrid inverter that’s built to handle it all—solar PV, batteries, grid tie-in, and even diesel generators for backup. This all-in-one unit seamlessly switches between on-grid and off-grid modes in under 10ms, so you won’t even notice outages, and it’s programmable to optimize energy use based on your needs, like peak shaving or self-consumption. With support for up to 45kW of PV input via MPPT, high-voltage battery compatibility, and the ability to parallel up to four units for quadruple capacity, it’s scalable for bigger demands. The touchscreen LCD makes monitoring a breeze, and with remote DG control, it’s perfect for off-grid sites. Tough enough for harsh environments with IP20 protection and a wide temp range, this inverter is all about reliability, efficiency, and cutting those energy bills while pushing for sustainability.
ATESS HPS30 hybrid inverter Key Features
- All-in-One Hybrid Design: Integrates battery, load, grid, solar, and generator connections for seamless on/off-grid operation with automatic transfer in ≤10ms.
- Scalable Paralleling: Connect up to 4 units for expanded capacity, ideal for commercial applications.
- Programmable Modes: Customizable working modes for energy management, including support for remote diesel generator control.
- High PV Input: Up to 45kWp PV power with MPPT voltage range of 480-800V DC for efficient solar harvesting.
- Battery Flexibility: Supports high-voltage batteries (352-600V) with 33kW charge/discharge power and up to 100A charging current.
- User-Friendly Interface: Touchscreen LCD for easy monitoring, plus RS485/CAN communication for integration.
- Robust Protection: IP20 rating, Type II lightning protection, and wide operating range (-25°C to +55°C) for durability.
ATESS HPS30 hybrid inverter Technical Data Table
| Specification | Value/Details |
|---|---|
| Rated AC Output Power | 30 kW |
| Apparent Power | 33 kVA |
| Rated AC Voltage | 400 V (3/N/PE) |
| Rated AC Current | 43 A |
| AC Voltage Range (Grid) | 360 V – 440 V |
| Rated Frequency | 50/60 Hz |
| Frequency Range (Grid) | 45-55 Hz / 55-65 Hz |
| THDU (Voltage Harmonic) | ≤2% linear |
| THDI (Current Harmonic) | <3% |
| Power Factor | 0.8 lagging to 0.8 leading |
| Overload Capability | 110% for 10 min, 120% for 1 min |
| Max. PV Input Power | 45 kWp |
| Max. PV Open-Circuit Voltage | 1000 V DC |
| PV MPPT Voltage Range | 480 V – 800 V DC |
| Battery Voltage Range | 352 V – 600 V |
| Battery Voltage at Max Charge | 450 V – 600 V |
| Max. Charge Power | 33 kW |
| Max. Discharge Power | 33 kW |
| Max. Charge Current | 100 A |
| Max. Discharge Current | 93 A |
| Max. Efficiency | Not specified (high efficiency implied) |
| Protection Degree | IP20 |
| Operating Temperature | -25°C to +55°C |
| Cooling | Forced-air |
| Noise Level | <65 dB(A) @1m |
| Relative Humidity | 0-95% non-condensing |
| Max. Altitude | 6000 m (derating >3000 m) |
| Dimensions (W x H x D) | 700 mm x 1660 mm x 600 mm |
| Weight | 355 kg |
| Display | Touchscreen LCD |
| Communication | RS485, CAN |
| Transfer Time (On/Off-Grid) | ≤10 ms |
| Standby Consumption | <30 W |
| Built-in Transformer | Yes |
| Lightning Protection | Type II |
| Parallel Capability | Up to 4 units |
| Certifications | CE, MEA, PEA, UKCA, AS4777.2, EN61000 series, EN50549-1, IEC62109, NRS097-2-1, G99, VDE-AR-N4105, etc. |
