ATESS HPS100 (100kw/110kVA) – 3P HYBRID INVERTER

KSh1,750,000.00

  • All-in-One Hybrid System: Integrates battery, load, grid, solar, and generator inputs for versatile on/off-grid operation with automatic seamless transfer in ≤10ms.
  • Scalable Paralleling: Up to 4 units can be paralleled, expanding capacity to 400kW or more for large commercial setups.
  • Programmable Operation Modes: Customizable for peak-shaving, backup, self-consumption, and includes remote control for diesel generators via dry contact.
  • High Solar Input Capacity: Supports up to 150kWp PV with MPPT range of 480-800V DC for optimal energy capture.
  • Battery Compatibility: Works with high-voltage batteries (352-600V) offering max 110kW charging and 100kW discharging power, up to 300A charging current.
  • Intuitive Interface: Touchscreen LCD for straightforward monitoring and setup, with RS485/CAN communication for system integration.
SKU: 10-ATT-0102 Categories: ,

Description

For those tackling large-scale industrial or commercial energy projects, the ATESS HPS100 hybrid inverter is a powerhouse 100kW three-phase hybrid inverter (110kVA apparent power) that’s engineered to manage solar PV, high-voltage batteries, grid connections, and diesel generators all in one robust package. Ideal for factories, warehouses, or remote sites, it offers seamless on-grid to off-grid switching in under 10ms, programmable modes for peak shaving, self-consumption, or backup power, and the flexibility to parallel up to four units for systems up to 400kW (or 600kW in some configs). With support for up to 150kWp of solar input and high charge/discharge rates, it’s built for efficiency and cost savings in demanding environments. The touchscreen interface simplifies monitoring, and its durable IP20 design with forced-air cooling ensures reliability even in tough conditions.

ATESS HPS100 hybrid inverter

ATESS HPS100 hybrid inverter Key Features

  • All-in-One Hybrid System: Integrates battery, load, grid, solar, and generator inputs for versatile on/off-grid operation with automatic seamless transfer in ≤10ms.
  • Scalable Paralleling: Up to 4 units can be paralleled, expanding capacity to 400kW or more for large commercial setups.
  • Programmable Operation Modes: Customizable for peak-shaving, backup, self-consumption, and includes remote control for diesel generators via dry contact.
  • High Solar Input Capacity: Supports up to 150kWp PV with MPPT range of 480-800V DC for optimal energy capture.
  • Battery Compatibility: Works with high-voltage batteries (352-600V) offering max 110kW charging and 100kW discharging power, up to 300A charging current.
  • Intuitive Interface: Touchscreen LCD for straightforward monitoring and setup, with RS485/CAN communication for system integration.
  • Rugged Construction: IP20 protection, -25°C to +55°C operating range, forced-air cooling, <65dB noise, and Type II lightning protection for enduring performance.

ATESS HPS100 hybrid inverter Technical Data Table

Specification Value/Details
Rated AC Output Power 100 kW
Apparent Power 110 kVA
Rated AC Voltage 400 V (3/N/PE)
Rated AC Current 144 A
AC Voltage Range (Grid) 360 V – 440 V
Rated Frequency 50/60 Hz
Frequency Range (Grid) 45-55 Hz / 55-65 Hz
THDU (Voltage Harmonic) ≤2% linear
THDI (Current Harmonic) <3%
Power Factor 0.8 lagging to 0.8 leading
Overload Capability 110% for 10 min, 120% for 1 min
Max. PV Input Power 150 kWp
Max. PV Open-Circuit Voltage 1000 V DC
PV MPPT Voltage Range 480 V – 800 V DC
Battery Voltage Range 352 V – 600 V
Battery Voltage at Max Charge 450 V – 600 V
Max. Charge Power 110 kW
Max. Discharge Power 100 kW
Max. Charge Current 300 A
Max. Discharge Current 313 A
Max. Efficiency Not specified (high efficiency implied)
Protection Degree IP20
Operating Temperature -25°C to +55°C
Cooling Forced-air
Noise Level <65 dB(A) @1m
Relative Humidity 0-95% non-condensing
Max. Altitude 6000 m (derating >3000 m)
Dimensions (W x H x D) 1200 mm x 1900 mm x 800 mm
Weight 948 kg
Display Touchscreen LCD
Communication RS485, CAN
Transfer Time (On/Off-Grid) ≤10 ms
Standby Consumption <30 W
Built-in Transformer Yes
Lightning Protection Type II
Parallel Capability Up to 4 units
Certifications CE, MEA, PEA, UKCA, AS4777.2, EN61000 series, EN50549-1, IEC62109, NRS097-2-1, G99, VDE-AR-N4105, etc.
