Suntree MC4 4-Branch Connector Pair
The Suntree MC4 4-Branch Connector Pair is a TUV-certified solution for parallel solar PV connections, linking four solar panels to a single output with high efficiency. Designed for Kenya’s demanding climates, this IP67-rated waterproof connector supports 4-6mm² cables, handling 30A at 1000V DC. Its flame-retardant PPO housing resists UV, heat, and impacts, ensuring reliable performance in Nairobi’s urban or rural off-grid setups. Quick to install with a secure snap-in design, it minimizes power loss and simplifies array expansion for residential or commercial solar systems, offering durability and seamless energy transfer.
Key Features
- IP67 waterproof rating for robust outdoor use in dust and rain.
- Supports 30A at 1000V DC for efficient solar power transfer.
- Fits 4-6mm² cables, compatible with standard PV wiring.
- TUV-certified for global safety and performance standards.
- Flame-retardant PPO material ensures UV and heat resistance.
- Low contact resistance (≤0.3mΩ) reduces energy loss.
- Tool-free snap-in installation for secure, reliable connections.
Suntree MC4 4-branch connector Technical Data Table
| Specification | Value | Notes/Source |
|---|---|---|
| Connector Type | MC4 4-Branch (1M+3F, 3M+1F) | Parallel connection for 4 panels |
| Rated Current | 30A | For AWG 10/12 cables |
| Rated Voltage | 1000V DC (TUV) | High-voltage PV systems |
| Cable Size | 4-6mm² (AWG 10/12) | Insulation diameter 3-6mm |
| Contact Resistance | ≤0.3mΩ | Minimizes power loss |
| Protection Class | IP67 | Waterproof and dustproof when connected |
| Temperature Range | -40°C to +90°C | Suitable for Kenyan climates |
| Material | PPO (flame-retardant), Copper (silver-plated) | UV-resistant, high-strength |
| Certifications | TUV | Meets international safety standards |
| Unmating Force | ≥200N | Secure locking mechanism |
