If you’re looking for a powerful and flexible solar charge controller, the Felicity 45 Amps MPPT Solar Charge Controller (12V/48V) is your perfect match. Whether you’re working with a 12V system or need to scale up to 48V, this Felicity MPPT Charge Controller 45A provides unmatched efficiency and precision. By tracking the Maximum Power Point of your solar panels, it ensures you capture the highest possible energy output, making it an ideal choice for anyone serious about maximizing their solar investment. At SolarShop Africa, we provide genuine Felicity solar charge controllers at competitive rates with full customer support.
Many Kenyans struggle to find trustworthy solar charge controllers prices in Kenya that balance quality with affordability. That’s where SolarShop Africa steps in. We offer the Felicity 45 Amps MPPT Solar Charge Controller with both 12V and 48V compatibility, giving you more flexibility for your system upgrades. Our clients rely on us for transparent pricing, fast nationwide delivery, and expert after-installation support to keep their systems running smoothly for years.
At SolarShop Africa, we don’t just sell products—we deliver reliable energy solutions. As industry leaders in Kenya’s solar sector, we ensure every Felicity MPPT Charge Controller 45A we supply is backed by rigorous quality checks and expert service. From seamless online ordering to doorstep delivery and installation assistance, we make adopting solar energy a hassle-free experience. Plus, with our competitive solar charge controllers prices in Kenya, you can shop with confidence knowing you’re getting premium products at the best rates. Choose SolarShop Africa today for genuine Felicity solar charge controllers that deliver long-term performance and peace of mind.
Felicity 45 Amps MPPT Solar Charge Controller 12V/48V Technical Specifications:
|
Model
|
FL-SCCM4524
|
FL-SCCM6048
|
FL-SCCM8048
|
FL-SCCM10048
|
FL-SCCM12048
|
|
Max PV Input Vol
|
145V
|
195V
|
|||
|
System Vol
|
12V/24V/48/(Auto dection)
|
||||
|
Max battery Charge Current
|
45A
|
60A
|
80A
|
100A
|
120A
|
|
PV Array MPPT Vol Range
|
15V-130VDC/ 30-130VDC/ 60-130V
|
15V-170V/ 30-170V/ 60-170V
|
|||
|
Max PV Input Power(12V)
|
625W
|
825W
|
1100W
|
1375W
|
1650W
|
|
Max PV Input Power(24V)
|
1250W
|
1650W
|
2200W
|
2750W
|
3300W
|
|
Max PV Input Power(48V)
|
2500W
|
3300W
|
4400W
|
5500W
|
6600W
|
|
Charge information
|
|||||
|
Charging Curve
|
See image below this sheet
|
||||
|
Charge Algorithm
|
3-Step
|
||||
|
Charging Stages
|
Bulk,Absorpotion,FloatBulk,Absorption,Float
|
||||
|
Temperature Compensation Coefficient
|
-5mV/℃/Cell/(25℃ref)
|
||||
|
Temperature Compensation Range
|
0℃ to 50℃
|
||||
|
Temperature Compensation Set Points
|
Absoption, Float Absoption, Float
|
||||
|
Charging Set Points
|
Absoption Stage, Float Stage
|
||||
|
Flooded Battery
|
14.6V/29.2V/58.4V
|
||||
|
ARG/Gel Battery(Default)
|
14.1V/28.2V/56.4V
|
||||
|
Overcharge voltage
|
15V/30V/60V
|
||||
|
Overcharge restart voltage
|
14.5V/29V/58V
|
||||
|
Battery discharge voltage
|
8.5V/17V/34V
|
||||
|
Battery overdischarge voltage
|
9V/18V/36V
|
||||
|
Mechanical & Environment
|
|||||
|
Size(H*W*D)
|
283*160*105mm
|
283*160*105
|
333*215*120mm
|
||
|
Weight
|
4.0KG
|
5.1KG
|
7.0KG
|
||
|
Ambient Temperature Range
|
0℃ to 50℃
|
||||
|
Storage Temperature Range
|
-40℃ to 75℃
|
||||
|
Humidity
|
0%-90%RH(No condensing)
|
||||
|
Enclosure
|
IP31(indoor&vented)
|
||||
