Freedom Won LiTE Marine 20/16 – 20 kWh 26 V Lithium Battery | Marine High-Capacity Energy Storage

KSh980,000.00

  • 10 kWh nominal capacity (8 kWh usable at 80 % DoD)

  • Available in 13 V, 26 V, and 52 V nominal options to support various systems

  • High continuous & peak currents: e.g. 300 A max, 300 A continuous at 26 V

  • Max recommended inverter output: 8 kVA in 26 V configuration

  • Integrated BMS: over/under-voltage, overcurrent, thermal protection, and cell balancing

SKU: 10-FRE-0107 Categories: ,

Description

Freedom Won LiTE Marine 20/16 is a high-capacity lithium iron phosphate (LiFePO₄) battery designed for marine, off-grid, and industrial applications. With a total energy capacity of 20 kWh and 16 kWh usable at 80 % depth of discharge (DoD), it offers a long service life of over 16 years at 80 % DoD. Available in 13 V, 26 V, and 52 V configurations, this battery provides flexibility to suit various system voltages. Its IP65-rated aluminium enclosure ensures durability and resistance to moisture and corrosion, making it ideal for marine environments. Equipped with a Battery Management System (BMS), it offers protection against overcharge, overdischarge, and short circuits, ensuring safe and reliable operation.

Key Features

  • Total Energy Capacity: 20 kWh

  • Usable Energy: 16 kWh at 80 % DoD

  • Nominal Voltage Options: 13 V, 26 V, 52 V

  • Max Discharge Current: 480 A

  • Max Charge Current: 400 A

  • Max Recommended Inverter Power:

    • 15 kVA (52 V)

    • 12 kVA (26 V)

    • 6 kVA (13 V)

  • Round-Trip Efficiency: 96–98 %

  • Service Life: Over 16 years at 80 % DoD

  • Enclosure: Aluminium, powder-coated, IP65-rated, corrosion-resistant

  • Protection: Integrated BMS with overcurrent, overvoltage, undervoltage, and short circuit protection

  • Cooling: Natural convection

Technical Data Table

Parameter Specification
Total Capacity 20 kWh
Usable Capacity (80 % DoD) 16 kWh
Nominal Voltage Options 13 V, 26 V, 52 V
Max Discharge Current 480 A
Max Charge Current 400 A
Max Inverter Power 15 kVA (52 V), 12 kVA (26 V), 6 kVA (13 V)
Round-Trip Efficiency 96–98 %
Service Life >16 years at 80 % DoD
Enclosure Aluminium, powder-coated, IP65-rated, corrosion-resistant
Protection BMS with overcurrent, overvoltage, undervoltage, and short circuit protection
Cooling Natural convection
Dimensions (H x W x D) 282 mm x 600 mm x 910 mm
Weight 173 kg
