Freedom Won Auxiliary FW12-200 – 2.56 kWh 12.8 V Lithium Battery | Compact High-Capacity Backup Storage

Description

Freedom Won 2.56 kWh lithium battery is a 12V 100Ah Lithium Iron Phosphate (LiFePO4) battery designed as a high-performance, drop-in replacement for traditional lead-acid batteries. With an energy rating of 1.28 kWh, it is built for a wide range of demanding applications, from renewable energy storage to marine use.

Key Features:

• Long Cycle Life: Offers over 2000 cycles at 100% depth of discharge (DOD), which is approximately five times longer than typical lead-acid batteries, minimizing long-term replacement costs .

• High Efficiency: Features a 100% charge efficiency at 0.5C and a discharge efficiency of 96-99% at 1C, ensuring minimal energy loss .

• Super-Safe Chemistry: The stable LiFePO4 chemistry eliminates the risk of explosion or combustion due to high impact, overcharging, or short circuits .

• Lightweight & Powerful: Weighing only about 13 kg, it is roughly 40% of the weight of a comparable lead-acid battery while delivering twice the power .

• Superior Flexibility: A modular design allows for deployment of up to four batteries in series and up to eight batteries in parallel to scale your power system .

• Built-in Protection: An integrated Battery Management System (BMS) provides comprehensive protection against over-charging, over-discharging, over-current, short circuits, and temperature extremes .

Technical Data Table

For a quick overview, here are the key technical specifications of the FW12-100 battery:
